ICON A5 - Baggage Floor Removal

INSPECTIONS / GENERAL INSPECTION TASKS 3-41
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
CHAPTER 3
None
Aircraft System and Number
NA
Consumables
None
TASK INSTRUCTIONS:
1. Install the inertia reel onto the 5/16 stud at the lower edge of the rear window.
2. Install the 5/16 washer and locknut, align the reel using the seat belt cover as a guide and torque
the nut to 85 in-lb.
3. Inspect the seat belt reel cover clips. If any are damaged, replace with new and use .020 safety
wire to secure them.
4. Snap the seat belt reel cover into place over the reel.
VERIFICATION METHOD:
Procedure is complete when seat belt inertia reel is installed.
RELATED INFORMATION:
"Baggage Sidewall Panel Installation" on page 3-45
"Rigging Roll Controls" on page 9-20
"Inspect Roll Cable Tension" on page 9-13
"Rigging Yaw Controls" on page 9-87
"Rigging Pitch Controls" on page 9-46
3.6.2.5 Baggage Floor Removal
Use the following procedure to remove the baggage floor.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
Line
Task Specific Training Required
No
Special Tools Required
None
Parts Required
