ICON A5 - Electrical System General Maintenance; Ignition Switch Replacement

ELECTRICAL SYSTEM / ELECTRICAL SYSTEM GENERAL MAINTENANCE 6-33
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
CHAPTER 6
6.4 Electrical System General Maintenance
6.4.1 Ignition Switch Replacement
The following is used to replace the ignition switch.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
03—Electrical System
Consumables
None
TASK INSTRUCTIONS:
1. Locate the ignition switch. Unscrew the pilot-facing cap to release the ignition switch from the
left hand crossbeam. Discard cap.
2. Reach behind the left hand crossbeam via the pilot footwell and disconnect the two push-on
terminals connected to the master switch.
3. Pull the ignition switch out from behind the left hand crossbeam.
4. Disconnect all ring terminals going to the ignition switch. Discard ignition switch.
5. Connect all ring terminals to the new ignition switch using diagram below.
6. Connect the two push-on terminals to the master switch using the diagram below.
