ICON A5 - Bilge Pump Installation (MY17)

6-44 ELECTRICAL SYSTEM / BILGE PUMP
ICON A5 / MAINTENANCE MANUAL CHANGE C2
CHAPTER 6
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
03—Electrical System
Consumables
None
TASK INSTRUCTIONS:
1. Remove the fuel tank. (See “Remove Fuel Bladder (MY17 Only)” on page 10-11.)
2. Remove the fuel tank mounting structure if unable to perform the below steps with it installed.
3. Reaching down behind the fuel tank mounting structure, disconnect the bilge pump hose from
the pump by loosening the hose clamp and pulling the hose off the pump’s barb.
4. Cut the cable tie attaching the pump to the carbon saddle.
5. Twist the pump to break it free from the adhesive and disconnect the pump body from the
bottom strainer by depressing the lock button and turning counter clockwise.
6. Remove the pump body and bottom strainer.
VERIFICATION METHOD:
The task is completed when the bilge pump has been removed.
RELATED INFORMATION:
"Remove Fuel Bladder (MY17 Only)" on page 10-11
6.6.3.3 Bilge Pump Installation (MY17)
The following task should be used to install the bilge pump (MY17).
TASK INFORMATION:
Type of Maintenance
