ICON A5 - Equipment and Furnishings General Maintenance; Seat Belt Replacement

EQUIPMENT AND FURNISHINGS / EQUIPMENT AND FURNISHINGS GENERAL MAINTENANCE 8-3
CHANGE C1 ICON A5 / MAINTENANCE MANUAL
CHAPTER 8
8.2 Equipment and Furnishings General Maintenance
8.2.1 Seat Belt Replacement
Use the following procedure to remove and install the seat belts.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
05—Equipment and Furnishings
Consumables
None
TASK INSTRUCTIONS:
1. Remove the baggage floors and seat back panel on the side of the seat belt to be removed. (See
“Baggage Floor Removal” on page 3-41.)( See “Seat Back Removal” on page 3-50.)
NOTE: Though not necessary, removal of the seat back and seat pan
makes the following steps easier. (See “Seat Pan Removal” on page
3-52.)
2. Remove the seat belt inertia reel.(See “Seat Belt Inertia Reel Removal” on page 3-39.)
3. Use 1/2 and 3/8 wrenches to remove the bolt and nuts securing the outboard end of the belt
assembly where it attaches to the outboard longeron. See Figure 8-1.
