ICON A5 - Maintenance Instructions; Fuel Level Sensor Replacement

6-72 ELECTRICAL SYSTEM / FUEL LEVEL SENSOR
ICON A5 / MAINTENANCE MANUAL CHANGE C2
CHAPTER 6
6.11.3 Maintenance Instructions
6.11.3.1 Fuel Level Sensor Replacement
Use the following task to replace the fuel level sensor.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
PROBE, FUEL LEVEL SENSOR
OPTICAL SENSOR
FUEL SENSOR GASKET
FUEL TANK ACCESS PLATE GASKET
Aircraft System and Number
03—Electrical System
Consumables
TY24MX (ZIP TIE)
LOCTITE 243 (THREADLOCKER)
GASKET SEALANT
TASK INSTRUCTIONS:
1. Remove the right seat back closeout. (See “Seat Back Removal” on page 3-50.)
2. Remove the right baggage floor. (See “Baggage Floor Removal” on page 3-41.)
3. Disconnect fuel level sensor connector from d9039p aircraft wire harness. Cut the zip ties
securing the wire harness.
4. Disconnect EXTERIOR SUPPLY LINE. See Figure 6-21.
5. Remove 12 AN3C4A BOLT and washers to remove FUEL TANK ACCESS PLATE from the FUEL
TANK ACCESS GASKET.
