8-12 EQUIPMENT AND FURNISHINGS / EQUIPMENT AND FURNISHINGS GENERAL MAINTENANCE
ICON A5 / MAINTENANCE MANUAL CHANGE C1
CHAPTER 8
FIGURE 8-8
STANDOFF REMOVAL
4. Remove throttle bezel along with the hour meter (connectors T9114(+) and T99105(-)). Label
each wire to ease reinstallation. The forward part of the bezel has two indexing tabs that slide
out from the center stack and center console panel assembly.
Standoff
Throttle Lever
(Reference)
