LANDING GEAR / MAIN LANDING GEAR 14-37
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
CHAPTER 14
14.6 Main Landing Gear
14.6.1 Maintenance Instructions
14.6.1.1 Main Landing Gear (MLG) Removal
Use the following procedure to remove the main landing gear (MLG) assembly.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
11—Landing Gear
Consumables
None
The procedure below removes both left and right MLG assemblies. If only removing one side, perform
only those steps needed.
CAUTION: Whenever standing, sitting, or kneeling inside the fuselage with
floor panels removed, suitable padding must be employed so as to
avoid damage to the bottom of the hull. Sandwich panels and other
structure and systems can be easily damaged by concentrated
applied loads.
TASK INSTRUCTIONS:
1. Remove the seat backs and baggage floors. (See “Seat Back Removal” on page 3-50.)(See
“Baggage Floor Removal” on page 3-41.)
2. Jack aircraft so that landing gear is clear of ground.
3. Remove the aft bulkhead baggage panel. (See “Baggage Sidewall Panel Removal” on page 3-43.)
4. Release the parking brake.
