3-44 INSPECTIONS / GENERAL INSPECTION TASKS
ICON A5 / MAINTENANCE MANUAL CHANGE C2
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
NA
Consumables
None
1. Remove the headliner. (See “Headliner Removal” on page 3-37.)
2. Remove the baggage floors. (See “Baggage Floor Removal” on page 3-41.)
3. Use a T20 Torx driver and 3/8 wrench to remove the seat back closeout associated with the
sidewall panel to be removed.
4. Remove the seat belt reel associated with the sidewall panel to be removed. (See “Seat Belt
Inertia Reel Removal” on page 3-39.)
5. Use a small cross head screwdriver or similar tool to press the center of the plastic push-type
fasteners in about 1/8 inch (don’t press too far or the center button will fall out the back side).
Doing so will release the expansion feature of the fastener. There are three of these fasteners in
each sidewall panel.
6. Lift the upper edge of the sidewall panel up and off the carbon retaining clips and remove from
the aircraft.
VERIFICATION METHOD:
The task is complete when the baggage sidewall panel has been completely removed.
