FLIGHT CONTROLS / PITCH CONTROLS 9-47
CHANGE C3 ICON A5 / MAINTENANCE MANUAL
Aircraft System
06—Flight Controls
Consumables
None
1. Remove water rudder access panel and AFT bulkhead baggage panel. (See “Removal and Instal-
lation of Inspection Panels and Fairings” on page 3-34.) (See “Baggage Sidewall Panel Removal”
on page 3-43.)
2. Remove left hand and right hand forward and main cockpit floor boards.(See “Cockpit Floor
Board Removal” on page 3-46.)
3. Remove seat back and seat pan. (See “Seat Back Removal” on page 3-50.) (See “Seat Pan
Removal” on page 3-52.) Retain all fastening hardware.
MS20392-1R4
3
PIN, STRAIGHT, HEADED, DRILLED SHANK 1
MS21043-4 NUT, SLFLKG, RDC HEX, CRES, .250-28 2
MS21251-B5L TURNBUCKLE BODY, CLIP LKG, BRASS, .156X.250-28X4.00 2
MS24566-4B PULLEY, CONT, AFB, .188X3.01 4
MS24665-151 PIN, COTTER, CRES, .063X.500 2
MS24665-153 PIN, COTTER, CRES, .063X.750 8
ICA002195 SECTOR, PITCH, FWD 1
ICA009551 DOWEL, PITCH SECTOR STOP 2
ICA009472 PLATE, ANTI ROT FLG, PITCH SECTOR STOP 2
WS-50-S16 RETAINING RING, EXT SPIRAL, 316 SST, .467X.045 2
AN3C10A BOLT, MACH, CRES, 10-32X.625 2
ICA012054 PUSHROD, ELEVATOR 1
91630A472 INSERT, HELICAL, SCREW LOCK, 18-8 SST, 10-32X.380 2
MS21256-2 CLIP, LKG, TRNBKL, 1.955 4
MS20995C20 WIRE, SAFETY, CRES, .020 1
ICA012237 BEARING, SLEEVE, NYLON, .625X.500X.750 4
Number Name Quantity
