FLIGHT CONTROLS / ROLL CONTROLS 9-21
CHANGE C3 ICON A5 / MAINTENANCE MANUAL
Aircraft System and Number
06—Flight Controls
Consumables
None
NOTE: Roll rigging sequence is from INBD to OUTBD
1. Remove left hand and right hand forward and main cockpit floor boards. (See “Cockpit Floor
Board Removal” on page 3-46.)
2. Remove seat back and seat pan. (See “Seat Back Removal” on page 3-50.)(See “Seat Pan
Removal” on page 3-52.) Retain all fastening hardware.
3. Remove baggage floor boards. (See “Baggage Floor Removal” on page 3-41.) Retain all fastening
hardware.
4. Remove seatbelt reel cover, left hand and right hand baggage sidewalls, and baggage headliner.
(See “Headliner Removal” on page 3-37.) If headliner cannot be removed without removal of
overhead console, temporary removal is permitted.
ICA008925 BUSHING, FLANGE, .250X.100X.032 4
ICA008926 BUSHING, FLANGE, .250X.132X.032 6
ICA009031 BUSHING, PLAIN, AL, .312X.250X.620 2
ICA009850 CABLE FAIRLEAD, OVERHEAD ROLL 2
ICA012104 CLIP, LOCKING, TURNBUCKLE, .042 WIRE 2
MS20220-2 PULLEY, GROOVE, FLIGHT CONTROL, 1680LB 2
MS20392-1R23 PIN, STR, HEADED, DRILLED SHK, CRES, .125X.719 4
MS20392-1R27 PIN, STR, HEADED, DRILLED SHK, CRES, .125X.844 8
MS21151-7 ROD END, BBRG, EXT THD, .250-28X.188 2
MS21251-B5S TURNBUCKLE BODY, CLIP LKG, BRASS, .156X.250-28X2.25 2
MS21256-1 CLIP, LKG, TRNBKL, 1.078 6
MS24566-4B PULLEY, CONT, AFB, .188X3.01 4
MS24665-151 PIN, COTTER, CRES, .063X.500 12
MS24694C101 SCREW, MACH, FLAT CSK HD, .250-28X.906X.375 2
NAS77C4-007 BUSHING, FLNGD, UNLINED, CRES, .250X.070 4
Part Number Part Name Quantity
