FUEL SYSTEM / FUEL SYSTEM GENERAL MAINTENANCE 10-9
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
FIGURE 10-1
FUEL SUPPLY HOSE AT THE FUEL RAIL
4. Connect a length of -6 AN fuel hose to the end of the supply hose and place the free end of the
hose into a suitable fuel container.
5. Turn on the aircraft master switch and rotate the ignition key to the first position—Lane A. This
will run the main boost fuel pump.
6. Leave the pump running until the desired amount of fuel is removed, then turn off ignition and
master switches.
CAUTION: Do not leave the fuel pump running unattended. Do not allow the
fuel pump to run dry for more than a few seconds.
7. Remove the added length of hose.
8. Reattach the fuel supply line to the fuel rail and torque to 110-130 in-lb with an 11/16 wrench.
9. Install the top engine cow. (See “Install Engine Cowlings” on page 16-16.)
VERIFICATION METHOD:
Verify that the fuel line is secured without any leaks. Verify that the Top Cowl is replaced and secured
into position.
