16-16 PROPULSION / ENGINE
ICON A5 / MAINTENANCE MANUAL CHANGE C2
6. Use a #20 Torx driver to remove the seven button head screws beginning with the RH fan shroud.
Remove fan shroud assembly.
To remove the muffler shields, follow Remove Exhaust System. (See “Remove Exhaust System” on
page 16-49.)
VERIFICATION METHOD:
Check the engine cowls and exhaust fairings removed for any damage.
RELATED INFORMATION:
"Inspect Engine Mount" on page 16-30
"Oil Cooler and Radiator Condition Inspection" on page 16-55
"Inspect Throttle Control for Proper Travel and Security" on page 16-32
"General Engine Line Maintenance" on page 16-26
"Install Engine" on page 16-21
"Engine Removal" on page 16-19
"Oil Cooler and Thermostat Removal" on page 16-79
"Oil Cooler and Thermostat Installation" on page 16-80
"Coolant Overflow Bottle Removal" on page 16-61
"Coolant Overflow Bottle Installation" on page 16-62
"Engine Coolant Replacement" on page 16-57
"Grease Coil Pack Connections" on page 16-39
"Inspect, Repair, and Secure Wiring Harness with Signs of Chafing" on page 6-34
"Balance Propeller" on page 16-95
"ELT Transponder and Transmitter Antenna Assembly" on page 13-55
"Remove Exhaust System" on page 16-49
16.1.4.2 Install Engine Cowlings
Use the following instructions to install top engine cowl, fan shrouds, and exhaust fairings.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
