16-30 PROPULSION / ENGINE
ICON A5 / MAINTENANCE MANUAL CHANGE C2
Parts Required
None
Aircraft System and Number
13—Propulsion
Consumables
LOCTITE
®
243™
1. Install the engine mount as shown in Figure 16-17. The single long screw is a 941487. The five
short screws are 840947. The washers are Nord-Lock NL10SS. Apply LOCTITE
®
243™ to the
screw threads on installation and torque each of the six screws to 30 ft-lb
f
.
NOTE: If spacers were removed and saved during the engine mount
removal, discard and do not reinstall.
2. Install the thermostat-radiator coolant hose where it attaches to the lower-right fitting at the
thermostat (Figure 16-16).
3. Connect the two coolant hoses where they attach to the lower water pump fittings as shown in
the upper image of Figure 16-15. Rotate the hose clamps on the hoses so the tabs are on top as
shown in the lower graphic in Figure 16-15 (this prevents tabs contacting the firewall during
engine installation).
VERIFICATION METHOD:
The procedure is complete when all the steps have been finished and the engine can be installed. (See
“Install Engine” on page 16-21.)
RELATED INFORMATION:
"Install Engine" on page 16-21
16.1.4.8 Inspect Engine Mount
Use the following to inspect the engine mount. This inspection requires the removal of the exhaust
headers and mufflers along with the entire cowling.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
