16-62 PROPULSION / ENGINE
ICON A5 / MAINTENANCE MANUAL CHANGE C2
CHAPTER 16
Parts Required
None
Aircraft System and Number
13—Propulsion
Consumables
None
TASK INSTRUCTIONS:
1. Remove the engine top cowling. (See “Remove Engine Cowlings” on page 16-13.)
2. Cut the cable tie and disconnect the black silicone hose from the bottom nipple on the overflow
bottle. Catch the coolant in a suitable container as it drains from the bottle and hose.
3. Remove the cap from the overflow bottle, cut the two cable ties securing the bottle to the mount
bracket and remove the bottle.
4. Carefully inspect the ICA011500 overflow bottle bracket for cracks, paying special attention to
the inside corners of cutouts where stress is highest. If damage is found, remove the bracket by
removing the two M8 and on M10 screws that attach it to the gearbox.
5. Inspect the yellow Tygon and black silicon hoses that attach to the bottle. If the hoses are stiff,
cracked or otherwise damaged, remove them by cutting the securing cable ties and hose clamps.
VERIFICATION METHOD:
Procedure is complete steps have been finished. If coolant overflow bottle needs replaced see instal-
lation procedure. (See “Coolant Overflow Bottle Installation” on page 16-62.)
RELATED INFORMATION:
"Remove Engine Cowlings" on page 16-13
"Install Engine Cowlings" on page 16-16
16.1.7.2.3 Coolant Overflow Bottle Installation
Use the following procedure to install the coolant overflow bottle.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
