PROPULSION / ENGINE 16-39
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
RELATED INFORMATION:
"Condition and 100-Hour Inspection—Engine and Propeller" on page 3-21
"Remove Engine Cowlings" on page 16-13
"Install Engine" on page 16-21
"Install Engine Cowlings" on page 16-16
16.1.4.10 Grease Coil Pack Connections
These instructions should be used to reapply dielectric grease to the primary side of the ignition coil
packs.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
03—Electrical System
Consumables
ICA012983 or 4CMPD150G TUBE (GREASE, DIELCTRIC, DC4)
TT-I-735A or equivalent (ISOPROPLY ALCOHOL)
The engine contains a total of four ignition coil packs located near the intake manifold at the top of the
engine as shown in Figure 16-25.
