6-68 ELECTRICAL SYSTEM / FUEL PRESSURE SENSOR
ICON A5 / MAINTENANCE MANUAL CHANGE C2
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
03—Electrical System
Consumables
None
1. Remove headliner. (See “Headliner Removal” on page 3-37.)
2. Turn fuel shutoff valve to the OFF position.
3. Disconnect D9036P on fuselage wire harness from PRESSURE SENSOR.
4. Remove PRESSURE SENSOR. Use backing wrench to hold the fuel pressure sensor adapter in
place prior to loosening up the sensor. (See Figure 6-20.)
CAUTION: Use a lot of rags to catch any liquid fuel from splattering around
cockpit.
