6-70 ELECTRICAL SYSTEM / FUEL PRESSURE SENSOR
ICON A5 / MAINTENANCE MANUAL CHANGE C2
CHAPTER 6
Parts Required
M_P75A-E4C (PRESSURE SENSOR, FUEL, 75PSI, .125NPT)
Aircraft System and Number
03—Electrical System
Consumables
LOCTITE 243 (THREADLOCKER, PRIMERLESS, OIL TOL, REMOVABLE MED STR, BLUE)
TT-I-735A or equivalent (ISOPROPYL ALCOHOL)
TT-M0261 or equivalent (MEK: METHYL ETHYL KETONE)
O-A-51 or equivalent (ACETONE)
ICA01209 (INSPECTORS LACQUER, ANTI SABOTAGE, ORANGE)
TASK INSTRUCTIONS:
1. Clean threads of PRESSURE SENSOR with ISOPROPYL ALCOHOL, MEK, OR ACETONE.
2. Apply THREADLOCKER to threads of the PRESSURE SENSOR. Install PRESSURE SENSOR 2
to 3 turns past finger tight into the fuel pressure sensor adapter. (See Figure 6-20.)
3. Check that hardware is secure on the supply line B-nuts. Torque B-nuts to 110-130 in-lb.
4. Connect D9036P on the fuselage wire harness to the PRESSURE SENSOR.
5. Install headliner. (See “Headliner Installation” on page 3-38.)
6. Turn fuel shutoff valve to the ON position.
VERIFICATION METHOD:
Pressure check fuel lines with fuel valve in ON position and both pumps running. Ensure no leaks are
visible.
RELATED INFORMATION:
"Headliner Installation" on page 3-38
