HORIZONTAL TAIL / HORIZONTAL TAIL GENERAL MAINTENANCE 12-9
CHANGE C1 ICON A5 / MAINTENANCE MANUAL
FIGURE 12-4
REMOVE SWITCHES FROM WIRING HARNESS
VERIFICATION METHOD:
Once the two limit switches are completely removed from horizontal tail, this task is complete.
RELATED INFORMATION:
"Horizontal Tail Removal" on page 12-11
"Removal and Installation of Inspection Panels and Fairings" on page 3-34
"Install Horizontal Tail Tip Lock Switches" on page 12-16
12.3.1.2 Air Rudder Removal
Use these instructions to remove the air rudder.
TASK INFORMATION:
Type of Maintenance
