13-12 INSTRUMENTS (AND AVIONICS) / TROUBLESHOOTING
ICON A5 / MAINTENANCE MANUAL CHANGE C2
CHAPTER 13
LAND AIRCRAFT
+
ALTERNATOR
+
BATTERY
+
ENGINE
Alternator A failure. Replace alternator. See “Rotax 912
iS Sport (912 iS 2) Heavy
Maintenance Manual” alternator
replacement.
Battery voltage is low (11-12 VDC). Test battery and replace if
necessary.
See “Battery Removal and
Installation” on page 6-37.
Battery not charging with engine
running.
Diagnose issue using wiring
schematics.
See “Electrical System Wiring
Diagrams” on page 6-4.
Alternator B failure. Replace alternator. See “Rotax
9912 iS Sport (912 iS 2) Heavy
Maintenance Manual” alternator
replacement.
BATTERY
Battery voltage is low (11-12 VDC). Test battery and replace if
necessary.See “Battery Diagnostic”
on page 6-32.
Battery not charging with engine
running.
See “Battery Diagnostic” on page
6-32.
Master Switch is OFF. Turn Master Switch ON.
30 amp circuit breaker pulled. Reset 30 amp circuit breaker.
Trouble Light Possible Cause Remedy
