LANDING GEAR / AFT NOSE LANDING GEAR DOOR 14-83
CHANGE C2 ICON A5 / MAINTENANCE MANUAL
CHAPTER 14
14.8 Aft Nose Landing Gear Door
14.8.1 Maintenance Instructions
14.8.1.1 Aft Nose Landing Gear (NLG) Door Mechanism Removal, Installation, and
Rigging
Use these procedures to remove, install, and repair the mechanism for the aft NLG doors.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
See task procedures.
Aircraft System and Number
11—Landing Gear
Consumables
None
NOTE: Carefully inspect each part and any underlying parts or structure
for serviceability prior to installation.
TASK INSTRUCTIONS:
1. Use standard practices to remove and install the components of the Aft Nose Landing Gear
Doors and mechanisms that need replacement or repair.
2. Verify Click Bond studs have been installed. The studs are bonded into the NLG box as shown.
Repeat this step for both LH and RH sides.
