15-6 PLACARDS AND MARKINGS / PLACARDS AND MARKINGS GENERAL MAINTENANCE
ICON A5 / MAINTENANCE MANUAL CHANGE C1
CHAPTER 15
15.2.1.8 Window Installation Procedure
Located on the window jamb beneath the removable windows (only visible when window is removed).
There are two per aircraft—one on the right side and one on the left side.
15.2.1.9 Wind Deflector Alignment and Instructions
Located on the wind deflector. There are two per aircraft—one on the right side and one on the left
side (when installed).
15.2.1.10 Window Out Warning
Located on inboard face of left hand wind deflector.
15.2.1.11 Keep Hands Clear
Located on the canopy jamb. There are two per aircraft—one on the right side and one on the left side.
15.2.1.12 Open Canopy
Located above the occupant seats under the canopy latch handle.
MAXIMUM SPEED
WINDOWS REMOVED
90 KIAS
K
E
E
P
H
A
N
D
S
C
L
E
A
R
