PLACARDS AND MARKINGS / PLACARDS AND MARKINGS GENERAL MAINTENANCE 15-9
CHANGE C1 ICON A5 / MAINTENANCE MANUAL
15.2.1.19 Parachute Handle
Located on the parachute handle.
15.2.1.20Parachute Activation Instructions
Located on the overhead console just in front of the parachute activation handle.
15.2.2 Exterior
15.2.2.1 Canopy Handle
Located on the center of the canopy; top side, next to the canopy release lever.
15.2.2.2 Danger Explosive
Located on the parachute egress panel adjacent to the engine on the root of the right wing.
