16-72 PROPULSION / ENGINE
ICON A5 / MAINTENANCE MANUAL CHANGE C2
CHAPTER 16
FIGURE 16-45
OIL THERMOSTAT CONNECTIONS
16.1.8.3 Maintenance Instructions
16.1.8.3.1 Remove Oil Tank
Use the following instructions to remove the oil tank.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
TANK-THERMOSTAT
HOSE
OIL COOLER
OIL THERMOSTAT
PLENUM AIR BOX
THERMOSTAT-OIL
COOLERLINE
OIL COOLER-THERMOSTAT
LINE
THERMOSTAT-ENGINE
HOSE
