2.9.2.17. Native PHY IP Parameter Settings for Basic, Basic with Rate Match
Configurations
This section contains the recommended parameter values for this protocol. Refer to
Using the Cyclone 10 GX Transceiver Native PHY IP Core for the full range of
parameter values.
Table 147. General and Datapath Options Parameters
Parameter Range
Message level for rule violations
error
warning
Transceiver configuration rules
Basic/Custom (Standard PCS)
Basic/Custom w/Rate Match (Standard
PCS)
PMA configuration rules basic
Transceiver mode
TX/RX Duplex
TX Simplex
RX Simplex
Number of data channels
1 to 12
Data rate
611 Mbps to 10.81344 Gbps
Enable datapath and interface reconfiguration On/Off
Enable simplified data interface On/Off
Table 148. TX PMA Parameters
Parameter Range
TX channel bonding mode Not bonded
PMA-only bonding
PMA and PCS bonding
PCS TX channel bonding master Auto, n-1 (where n = the number of data
channels)
Actual PCS TX channel bonding master n-1 (where n = the number of data channels)
TX local clock division factor 1, 2, 4, 8
Number of TX PLL clock inputs per channel 1, 2, 3, 4
Initial TX PLL clock input selection 0 (Depends on the Number of TX PLL clock
inputs per channel value)
Enable tx_pma_clkout port On/Off
Enable tx_pma_div_clkout port On/Off
tx_pma_div_clkout division factor Disabled, 1, 2, 33, 40, 66
Enable tx_pma_elecidle port On/Off
Enable rx_seriallpbken port On/Off
2. Implementing Protocols in Intel Cyclone 10 GX Transceivers
UG-20070 | 2018.09.24
Intel
®
Cyclone
®
10 GX Transceiver PHY User Guide
Send Feedback
182
