Intel Cyclone 10 GX User Manual

Table 149. RX PMA Parameters
Parameter Range
Number of CDR reference clocks 1, 2, 3, 4, 5
Selected CDR reference clock 0, 1, 2, 3, 4
Selected CDR reference clock frequency Legal range defined by Quartus Prime software
PPM detector threshold 100, 300, 500, 1000
CTLE adaptation mode manual
Enable rx_pma_clkout port On/Off
Enable rx_pma_div_clkout port On/Off
rx_pma_div_clkout division factor Disabled, 1, 2, 33, 40, 50, 66
Enable rx_pma_clkslip port On/Off
Enable rx_is_lockedtodata port On/Off
Enable rx_is_lockedtoref port On/Off
Enable rx_set_locktodata and rx_set_locktoref ports On/Off
Enable rx_seriallpbken port On/Off
Enable PRBS verifier control and status ports On/Off
Table 150. Standard PCS Parameters
Parameter Range
Standard PCS / PMA interface width 8, 10, 16, 20
FPGA fabric / Standard TX PCS interface width 8, 10, 16, 20, 32, 40
FPGA fabric / Standard RX PCS interface width 8, 10, 16, 20, 32, 40
Enable 'Standard PCS' low latency mode
On/Off
Off (for Basic with Rate Match)
TX FIFO mode
low_latency
register_fifo
fast_register
RX FIFO Mode
low_latency
register_fifo
Enable tx_std_pcfifo_full port On/Off
Enable tx_std_pcfifo_empty port On/Off
Enable rx_std_pcfifo_full port On/Off
Enable rx_std_pcfifo_empty port On/Off
TX byte serializer mode
Disabled
Serialize x2
Serialize x4
RX byte deserializer mode
Disabled
Deserialize x2
Deserialize x4
Enable TX 8B/10B encoder On/Off
continued...
2. Implementing Protocols in Intel Cyclone 10 GX Transceivers
UG-20070 | 2018.09.24
Send Feedback
Intel
®
Cyclone
®
10 GX Transceiver PHY User Guide
183
