Konica Minolta Image Controller IC-402 - Specifying Settings for SMB Server Transmissions; Checking Copier SMB Settings; To Check the SMB Setting; Checking TCP;IP Settings

Specifying Network Scanning Settings
5
IC-402 5-11
5.6 Specifying Settings for SMB Server Transmissions
Checking Copier SMB Settings
In order to send data to a server (SMB), the following copier parameter must
be set to “ON”.
To check the SMB setting
1 From the copier’s control panel, display the Administrator Setting
screen.
2 Touch [Network Setting], then [SMB Setting], and then specify the fol-
lowing setting.
Checking TCP/IP Settings
In the setup screen for the image controller, select [Network Setup] — [Pro-
tocol Setup] — [TCP/IP Setup] to check whether or not transmissions are
permitted with the TCP/IP protocol. If it is not permitted, specify the setting
that allows transmissions with the TCP/IP protocol.
Item Description
SMB TX Setting Select “ON”.
