Scanning Documents
2
IC-402 2-3
6 [Scan] key Press to enter Scan mode. While the machine is in
Scan mode, the indicator on the [Scan] key lights
up in green.
For details, refer to this manual.
7 [Copy] key Press to enter Copy mode. (As a default, the
machine is in Copy mode.) While the machine is in
Copy mode, the indicator on the [Copy] key lights
up in green.
For details, refer to the User’s Guide [Copy Opera-
tions].
8 [Reset] key Press to clear all settings (except programmed
settings) entered in the control panel and touch
panel.
9 [Interrupt] key Press to enter Interrupt mode. While the machine is
in Interrupt mode, the indicator on the [Interrupt]
key lights up in green and the message “Now in
Interrupt mode.” appears on the touch panel. To
cancel Interrupt mode, press the [Interrupt] key
again.
10 Auxiliary power button Press to turn on/off machine operations, for exam-
ple, for copying, printing or scanning. When turned
off, the copier enters a state where it conserves en-
ergy.
11 [Stop] key Press the [Stop] key during scanning to stop the
scan operation.
12 [Start] key Press to start scanning. When the copier is ready to
begin scanning, the indicator on the [Start] key
lights up in green. If the indicator on the [Start] key
lights up in orange, scanning cannot begin.
Press to restart a stopped job.
13 Main Power indicator Lights up in green when the copier is turned on with
the auxiliary power button
14 Data indicator Flashes in green while a print job is being received.
Lights up in green when data is being printed.
15 [Proof Copy] key Press to print a single proof copy to be checked
before printing a large number of copies.
16 Keypad Use to type in the number of copies to be
produced.
Use to type in the zoom ratio.
Use to type in the various settings.
17 [C] (clear) key Press to erase a value (such as the number of
copies, a zoom ratio, or a size) entered using the
keypad.
18 [Mode Check] key Press to display screens showing the specified
settings.
19 [Utility/Counter] key Press to display the Utility screen and Meter Count
screen.
20 [Mode Memory] key Press to register the desired copy settings as a pro-
gram or to recall a registered copy program.
21 Contrast dial Use to adjust the contrast of the touch panel.
No. Part Name Description
