15 Parameter reference
15.3 Overview of all parameters with power-related Lenze setting
1158
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Mains voltage / device power
3 * 400 V
Parameters Name Unit 2.2 kW 3.0 kW 4.0 kW 5.5 kW 7.5 kW 11 kW 15 kW 18 kW 22 kW 30 kW 37 kW 45 kW
C00016 VFC: Vmin boost % 2.25 2.48 2.06 1.94 1.7 1.47 1.36 1.32 1.24 0.97 0.7 0.59
C00021
Slip comp. % 4 4.673.333.67 3 2.672.67 2 2.932.331.131.33
C00022
Imax in motor mode A 9.8 12.77 16.62 22.75 28.87 41.12 56 68.25 82.25 103.25 126 155.75
C00070/1
SLVC: Vp speed controller 15.76 11.4 15.42 14.05 26 32.41 29.22 43.23 40.95 36.28 75.12 72.06
C00070/2
SC: Vp speed controller 9.01 6.51 8.81 8.03 14.86 18.52 16.7 24.7 23.4 20.73 42.93 41.18
C00070/3
SLPSM: Vp speed controller 2.25 1.63 2.2 2.01 3.72 4.63 4.18 6.18 5.85 5.18 10.73 10.3
C00073/1
VFC: Vp Imax controller 0.2 0.23 0.17 0.17 0.14 0.11 0.11 0.08 0.12 0.1 0.09 0.09
C00074/1
VFC: Ti Imax controller ms 65 65 65 65 65 750 750 750 750 750 750 750
C00075
Vp current controller V/A 17 14.2 11.1 6.97 8.1 7 5.5 4 3.8 1.8 1.49 1.06
C00076
Ti current controller ms 4.25 4.38 5.34 4.77 8.62 10.61 11.96 10.53 12.67 10.59 14.57 15.17
C00077
SC: Vp field controller 5.46 5.4 8.44 7.29 7.67 12.8 14.84 19.74 21.47 31.45 35.17 35.59
C00078
SC: Tn field controller ms 109.2 108.1 168.8 145.9 153.3 256 296.7 394.7 429.3 500 997 859
C00081
Rated motor power kW 2.2 3 4 5.5 7.5 11 15 18.5 22 30 37 45
C00082
Motor rotor resistance mOhm 2220 1938 1262 842 642 276 186 168 130 111 36 29
C00084
Motor stator resistance mOhm 2000 1620 1040 730 470 330 230 190 150 85 51 35
C00085
Motor stator leakage inductance mH 8.5 7.1 5.55 3.49 4.05 3.5 2.75 2 1.9 0.9 0.74 0.53
C00087
Rated motor speed rpm 1440 1430 1450 1445 1455 1460 1460 1470 1456 1465 1483 1480
C00088
Rated motor current A 5.3 7.2 9.3 12.5 17 21 27.8 32.8 38.8 53.9 65 79
C00090
Rated motor voltage V 400 400 400 400 400 400 400 400 400 400 400 400
C00091
Motor cosine phi 0.730.750.730.770.760.850.87 0.9 0.9 0.870.870.88
C00092
Motor magnetising inductance mH 210 168 170 103 68 81 65.5 73 62.5 52.6 35.1 24.4
C00093
Power section ID 2224 3024 4024 5524 7524 1134 1534 1834 2234 3034 3734 4534
C00095
Motor magnetising current A 3.2 4 4.1 6.7 10.2 8.5 10.5 9.5 11.1 13.2 20.5 29.5
C00098
Rated device current A 5.67.39.51316.523.5323947597289
C00129
Brake resistance value Ohm 18082474727271815157.57.57.5
C00130
Rated brake resistor power W 300 200 400 800 600 1200 1400 1200 1200 1900 1900 1900
C00131
Rated heat amount of brake resist. kWs 45 30 60 120 120 90 210 180 180 285 285 285
C00497
Filter time constant ms 111122222222
C00916
Motor cable cross-section mm^21.52.52.52.546666101010
C00966
VFC: Time const. slip comp. ms 100 100 139 126 112 306 367 446 495 489 1016 877
C00982 VFC-ECO: Voltage reduction ramp s 0.30.30.40.80.80.81.11.31.51.51.51.5
C00987
Inverter motor brake: nAdd rpm 1201401001109080806088706060
C00993
Flying restart: Integration time ms 300 300 417.3 379.4 336.7 1159.4 1237.3 1387.3 1265.1 1445 2989.5 2577.3
