Diagnostic aids 3-11
5026
Tray 4 (if installed)
Tray 5 (if installed)
Multi-Purpose Feeder (if installed)
3. Select Single or Continuous, and press Select ().
• If Single is selected, a single page is printed.
• If Continuous is selected, printing continues until Stop ( ) is pressed to cancel the test.
If a source is selected that contains envelopes, an envelope test pattern is printed. If Continuous is
selected, the test pattern is printed only on the first envelope.
Note: The Print Test Page always prints on one side of the paper, regardless of the duplex setting.
4. Press Back ( ) to return to PRINT TESTS.
Print quality test pages (Prt Quality Pgs)
The print quality test consists of five pages. Pages one and two contain a mixture of graphics and text. The
remainder of the pages only contain graphics. The test prints on the media in the default tray.
This test may be printed from either Configuration Menu or the Diagnostics mode. To run the print quality pages
from the Diagnostics mode, select PRINT TESTS and Print Quality Pgs from the menu. Once the test is
started, it cannot be canceled. When the test pages print, the printer returns to the original screen.
To run the Print Quality Test Pages, select Prt Quality Pgs from PRINT TESTS, and press Select ( ). The
message Printing Quality Test Pages is displayed, and the test prints.
