Auger drive removal

See “Auger shaft and gear parts pack” on page 7-11 for the part number.

1. Remove the paper pick mechanism assembly. See “Paper pick mechanism assembly removal”.

2. Remove the left cover. See “Left cover removal”.

3. Remove the six mounting screws (A) holding the HVPS in place.
