Lexmark C734dn Service Manual

Diagnostic information 2-3
5026
Go Back
Previous
Next
Administrative menus
Press Menu ( ) to enter the Administrative menus.
Note: Some menu items may not be available based on the printer model or the options installed.
Back Press to return to the previous screen.
Note: This button is only active if appears on the top left of the screen.
USB direct port Insert a USB flash drive to send data to the printer.
Numeric keypad Consists of the numbers 0–9, a backspace button, and a pound (#) button.
Button or light Function
Supplies Menu Paper Menu Reports Settings
Replace Supply Default Source Menu Settings Page General Settings
Cyan Cartridge Paper Size/Type Device Statistics Setup Menu
Magenta Cartridge Configure MP Network Setup Page Finishing Menu
Yellow Cartridge Substitute Size Network <x> Setup Page Quality Menu
Black Cartridge Paper Texture Wireless Setup Page Utilities Menu
Cyan PC Unit Paper Weight Profiles List XPS Menu
Magenta PC Unit Paper Loading NetWare Setup Page PDF Menu
Yellow PC Unit Custom Types Print Fonts PostScript Menu
Black PC Unit Universal Setup Print Directory PCL Emul Menu
Waste Toner Box Print Demo PPDS Menu
Fuser Asset Report HTML Menu
Transfer Module Image Menu
PictBridge Menu
Flash Drive Menu
Security Network/Ports Help
Miscellaneous Security Setting Active NIC Print All
Confidential Print Standard Network* Color Quality
Disk Wiping Standard USB Print Quality
Security Audit Log Standard Network Printing Guide
Set Date/Time Parallel <x> Media Guide
Serial <x> Print Defects
SMPT Setup Menu Map
Information Guide
Connection Guide
Moving Guide
Supplies Guide
* Depending on the printer setup, this menu item appears as Standard Network, Wireless Network,
or Network <x>.
