3-20 Service Manual
5026
Printer Setup
Defaults
U.S./Non-U.S. defaults changes whether the printer uses the U.S. factory defaults or the non-U.S. factory
defaults. The settings affected include paper size, envelope size, PCL symbol set, code pages, and units of
measure.
Warning: Changing this setting resets the printer to factory defaults, and data may be lost. It cannot be undone.
Page Counts
You can view, but not change any of the three counts displayed under PAGE COUNTS.
To view the Prt Color Pg Count, the Prt Mono Pg Count, or the Perm Page Count:
1. Select PRINTER SETUP from DIAGNOSTICS, and press Select ().
2. Select PAGE COUNTS, and press Select ().
3. Select the page count you wish to view:
• Prt Color Pg Count
• Prt Mono Pg Count
• Perm Page Count
Press Back (
) to return to PRINTER SETUP.
Serial Number
The serial number can only be viewed and cannot be changed.
To view the serial number:
1. Select PRINTER SETUP from DIAGNOSTICS, and press Select ().
2. Select Serial number, and press Select ().
Press Back (
) to return to PRINTER SETUP.
Engine Setting 1 through 4
Warning:Do not change these settings unless requested to do so by your next level of support.
Model Name
The model name can only be viewed and cannot be changed.
Configuration ID
The two configuration IDs are used to communicate information about certain areas of the printer that cannot be
determined using hardware sensors. The configuration IDs are originally set at the factory when the printer is
manufactured. However, the servicer may need to reset Configuration ID 1 or Configuration ID 2 whenever the
system board is replaced. The IDs consist of eight digits. The first seven digits in each ID are hexadecimal
numbers, while the last digit is a checksum of the preceding seven digits. Each ID can contain a combination of
the digits 0 through 9, and A through F.
Note: When the printer detects a Configuration ID that is not defined or invalid, the following occurs:
• The default standard model Configuration ID is used instead.
• Configuration ID is the only function available in DIAGNOSTICS.
• Unless the menu is in DIAGNOSTICS, Check Config ID displays.
