Repair information 4-35

5026

Go Back

Rear right cover removal

See “Rear right cover” on page 7-3 for the part number.

1. Remove the right cover. See “Right cover removal” on page 4-37.

2. Press the two tabs (A) to separate the right cover from the rear right cover.
