Parts catalog 7-15

5026

Go Back

Assembly 9: Optional special media tray assembly

Index P/N

Units/

opt.

Units/

FRU

Description

9—1 40X5142 1 1 Special media assembly, including tray

2 40X5152 2 2 Pick arm roll, 550-sheet drawer

3 40X5143 1 1 Special media tray assembly
