Hardware Tests
Panel Test
This test verifies the operator panel LCD function.
To run the Panel Test:
1. Select HARDWARE TESTS from DIAGNOSTICS, and press Select ().
2. Select Panel Test, and press Select ().
The Panel Test continually executes. Each pixel is activated at the darkest level to the lightest level, and
then the backlight illuminates and turns off. This is repeated continuously.
3. Press Stop ( ) to cancel the test at any point.
Button Test
This test verifies the operator panel button function.
To run the Button Test:
1. Select Button Test from HARDWARE TESTS from Diagnostics, and press Select ().
2. Press each button one at a time, and an X appears in the box that represents that button.
When you press Stop ( ), the test ends.
Press Stop ( ) to cancel the test.
DRAM Test
This test checks the validity of DRAM, both standard and optional. The test writes patterns of data to DRAM to
verify that each bit in memory can be set and read correctly.
To run the DRAM Test select DRAM Test from HARDWARE TESTS in DIAGNOSTICS, and press Select ().
The power indicator blinks indicating the test is in progress.
Note: If you need to exit the test before it is complete, turn off the printer.
P:###### represents the number of times the memory test has passed and finished successfully. Initially,
000000 displays with the maximum pass count being 99,999.
F:##### represents the number of times the memory test has failed and finished with errors. Initially, 00000
displays with the maximum fail count being 99,999.
Once the maximum pass count or fail count is reached, the test is stopped, the power indicator turns on solid,
and the final results appear. If the test fails, SDRAM Error appears for approximately three seconds and the
failure count increases by 1.
DRAM Test 128M
P:###### F:#####
