1-4 Service Manual
5026
Clearances
Memory
Number Description Clearance
1 Rear 100 mm (3.9 in.)
2 Right side 100 mm (3.9 in.)
3 Front 400 mm (15.7 in.)
4 Left side 150 mm (5.9. in.)
5 Above 150 mm (5.9 in.)
Memory
All models
Standard memory—The standard RAM is soldered onto the system board.
Memory size
256MB
Optional memory—Optional DIMM (Dual Inline Memory Module) is a card that can be plugged into an
available memory slot on the system board. Flash memory is a card that can also be plugged into an
available slot.
Maximum number of memory (DIMM) slots
1
Maximum number of flash memory slots
1
DIMM memory sizes available
256MB, 512MB, 1024MB
Flash (Nand Flash)
256
Maximum possible memory
1280MB
