Diagnostic aids 3-21
5026
To set the configuration ID:
1. Select Printer Setup from the Diagnostic mode.
2. Select Configuration ID from the Printer Setup menu.
Submitting Selection displays, followed by the value for Configuration ID 1.
3. Enter the Configuration ID 1.
• To select a digit or character to change, press or until the digit or character is underlined.
• To change a digit or character, press to increase or to decrease the value.
• After the last digit is changed, press Select ( ) to validate the Configuration ID 1.
If Invalid ID appears, the entry is discarded, and the previous Configuration ID 1 is displayed on the
screen.
If the process is successful, Submitting Selection appears on the display, followed by the current
value for Configuration ID 2.
4. Repeat the steps for entering the Configuration ID, and press Select ().
If the Configuration ID 2 is validated, Submitting Selection appears, and a check ( ) appears next to
Printer Setup.
Note: The printer will NOT perform an automatic POR after the Configuration IDs are accepted.
Reset color calibration (Reset Color Cal)
The Reset Color Cal enables the alignment of the color planes using pre-programmed values. Automatic Color
Adjust Calibration may be more effective.
1. Select PRINTER SETUP in the Diagnostics Menu, and press Select ().
2. Select Reset Color Cal, and press Select ().
The following screen displays:
Then the following screen is displayed:
3. The printer returns to the previous screen when calibration is complete.
Parallel 1 strobe adjustment (Par 1 Strobe Adj)
Note: This setting appears only if the printer has a parallel port available in the PCI slot 1.
This setting enables the servicer to adjust the amount of time the strobe is sampled in order to determine if valid
data is available on the parallel port. The range of values is -4 to 6. Each time this value is incremented by 1, the
strobe is sampled 50 ns (nanoseconds) longer. Each time this value is decreased by 1, the strobe is sampled 50
ns less often. When the value of this setting is 0, the factory default is used to determine the length of time the
strobe is sampled. If the servicer, for example, decreased the value from 0 to 3, the strobe will be sampled for
150 ns longer than the factory setting.
Motor Calibration
This test is run to calibrate the leading edge of the paper to each transfer station.
1. Select MOTOR TESTS from DIAGNOSTICS, and press Select ().
2. Select Motor Calibration, and press Select ().
The printer generates eight pages as part of this test.
To stop the test, press Stop ().
PRINTER SETUP
Reset Calibration
Resetting
Calibration
