Diagnostic aids 3-33
5026
Go Back
Previous
Next
3. Press the waste toner release latch (C), swing the front of the waste toner assembly away from the printer,
and remove.
4. Remove the two screws (D) on the bottom and one screw higher up (E).
5. Press the locking tab (F).
DE
F
