3-42 Service Manual
5026
c. Lift the unit and pull forward to remove it.
d. Remove the jammed paper.
e. Replace the fuser unit, and then turn the screws to the right to fasten it securely.
3. Close the top cover, and then close the front door.
4. Press Select ().
202 paper jam
If paper is jammed both under the fuser unit and in the slot behind the fuser unit, 202.xx Paper jam appears.
1. If the paper is visible in the standard exit bin, grasp the paper and pull it away from the bin.
2. Open the front door, and then open the top cover.
3. Grasp the paper on each side, and pull it forward.
