3-44 Service Manual
5026
203 paper jam
If paper is jammed under the rollers near the fuser, or in the standard exit bin 203.xx Paper jam appears.
1. Grasp the paper that is visible in the standard exit bin, and pull it away from the bin.
2. Open the front door, and then open the top cover.
3. Grasp the paper on each side, and pull it out gently.
4. Close the top cover, and then close the front door.
5. Press Select ().
230 paper jam
If paper is jammed between the front door and tray 1, 230.xx Paper jam appears.
1. Remove tray 1.
2. Open the front door.
3. Pull straight up to remove the jammed paper.
4. Close the front door.
