4-30 Service Manual

5026

Go Back

5. Disconnect the operator panel cable (D).

6. Turn over the operator panel card.

Note: Do not disconnect the display cables. Be sure not to put any pressure on the ribbon cable.

7. Remove the clear shield over the number pad.

8. Remove the buttons (E) from the top access door cover.
