4-60 Service Manual

5026

Go Back

2. For black:

a. Remove the screw (D) from the lower-most cartridge guide.

b. Gently pull the cartridge guide, then remove the front (E) or rear (F) cartridge guide wheel.

CAUTION: Do not pull too hard on the cartridge guide to avoid damage.
