Repair information 4-87

5026

Go Back

14. Remove the 5 V interlock switch cable from the restraint (N) on the backside of the EP drive.

15. Remove the EP drive.

Installation notes:

1. Push the actuator rack all the way to the right (A).

2. Pull the link all the way up (B).
