4-98 Service Manual
5026
6. Remove the left cover. See “Left cover removal” on page 4-21.
7. Using a flathead screwdriver, rotate the top cover camshaft clockwise to raise the front door locking
mechanism (G).
8. Close the front access door assembly.
9. Release the cable spring (H) from the front door assembly.
Note: In order to access the springs, make sure the top access cover is closed.
To Next Page
