4-102 Service Manual
5026
6. Remove the right cover. See “Right cover removal” on page 4-37.
7. Close the front access door assembly.
8. Release the spring (G) from the front door assembly.
Note: In order to access the springs, make sure the top access cover is closed.
9. Remove the end of the cable (H) from the frame.
10. Remove the right restraint cable.
To Next Page
