Lexmark C734dn Service Manual

Parts catalog 7-19
5026
Go Back
Previous
Next
Assembly 11: Options and features
Index P/N
Units/
mach
Units/
FRU
Description
11—1 40X5038 1 1 Wireless network card (802.11g), US/Americas
1 40X5039 1 1 Wireless network card (802.11g), rest of world
2 40X5319 1 1 Wireless antenna (802.11)
NS 40X5317 1 1 Parts packet, ISP thumbscrew and standoff
NS 40X5315 1 1 Wireless ISP thumbscrew
NS 40X5318 1 1 ISP thumbscrew
NS 40X5136 1 1 Parts packet, screw (contains each screw used in the printer, with the
exception of the parts specifically called out.) See “Screw and retainer
identification table” on page 4-3.
NS 40X5301 1 1 256 MB SDRAM
NS 40X5302 1 1 512 MB SDRAM
NS 40X5303 1 1 1024 MB SDRAM
NS 40X5704 1 1 256 MB flash card
NS 40X5969 1 1 Korean font card
NS 40X5971 1 1 Traditional Chinese font card
NS 40X5970 1 1 Simplified Chinese font card
NS 40X5972 1 1 Japanese font card
NS 40X0038 1 1 Bar code and Forms card
NS 40X5952 1 1 Lexmark PrintCryption™ card
NS 40X4826 1 1 MarkNet™ N8120 10/1000
NS 40X4827 1 1 MarkNet N8130 10/100 fiber
NS 40X4823 1 1 Parallel 1284-B interface card adapter
NS 40X4819 1 1 Serial interface card adapter
NS 40X4822 1 1 80.0 GB hard disk assembly
NS 40X5283 1 1 Printer relocation kit
NS 7377200 1 1 Option drawer relocation kit
NS 40X5281 1 1 High-capacity input tray (HCIT) relocation kit
NS 40X5316 1 1 14-pin JST cable assembly for ISP interface cable
NS 40X0063 1 1 Card for IPDS and SCS/TNe
