2-62 Service Manual
5026
9
1. Replace the fuser. See “Fuser removal”
on page 4-104.
2. Bring the printer up in Diagnostics Menu
(turn off the printer, press and hold and
. and turn on the printer).
3. Select SENSOR TESTS, and press
Select ().
4. Select Dynamic Sensors, and press
Select ().
5. Select Fuser Exit, and press
Select ().
6. Open the front access door and the top
access cover.
7. Did the fuser exit sensor change from
Open to Closed?
Problem resolved Replace the system board.
See “System board
removal” on page 4-153.
Step Questions / actions Yes No
To Next Page
