Mazda 6 2002 - Page 1130

U40
CONTROL SYSTEM
End Of Si e
AMBIENT TEMPERATURE SENSOR INSPECTION
A6E854061764W02
1. Measure the temperature around the ambient temperature sensor.
2. Measure the resistance between terminals of the
ambient temperature sensor.
• If the resistance is not as shown in the graph,
replace the ambient temperature sensor.
End Of Sie
CABIN TEMPERATURE SENSOR REMOVAL/INSTALLATION
A6E854061757W01
1. Disconnect the negative battery cable.
2. Remove the lower panel. (See S84 LOWER PANEL REMOVAL/INSTALLATION.)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.
End Of Sie
A6E8540W019
1Air hose
2 Cabin temperature sensor connector
3 Cabin temperature sensor
A6E8540W020
