Mazda 6 2002 - Dtc P0500

ON-BOARD DIAGNOSTIC
K55
K
End Of Sie
DTC P0500
A6E567001030W05
P0762 Shift solenoid C stuck ON ON YES 2 CCM ×
(See K95 DTC
P0762)
P0763 Shift solenoid C malfunction (electrical) ON YES 1 CCM ×
(See K96 DTC
P0763)
P0766 Shift solenoid D stuck OFF ON YES 2 CCM ×
(See K99 DTC
P0766)
P0767 Shift solenoid D stuck ON ON YES 2 CCM ×
(See K100
DTC P0767)
P0768 Shift solenoid D malfunction (electrical) ON YES 1 CCM ×
(See K102
DTC P0768)
P0771 Shift solenoid E stuck OFF ON YES 2 CCM ×
(See K104
DTC P0771)
P0772 Shift solenoid E stuck ON ON YES 2 CCM ×
(See K105
DTC P0772)
P0773 Shift solenoid E malfunction (electrical) ON YES 1 CCM ×
(See K107
DTC P0773)
P0841 Oil pressure switch circuit malfunction OFF NO 2 CCM ×
(See K109
DTC P0841)
P0850 Neutral switch input malfunction (See F67 DTC TABLE)
P1410 Variable air duct valve circuit malfunction (See F67 DTC TABLE)
P1562 PCM +BB voltage low (See F67 DTC TABLE)
P2006 VTCS stuck close (See F67 DTC TABLE)
P2009 VTCS circuit low input (See F67 DTC TABLE)
P2010 VTCS circuit high input (See F67 DTC TABLE)
P2228 BARO sensor circuit low input (See F67 DTC TABLE)
P2229 BARO sensor circuit high input (See F67 DTC TABLE)
P2502 Generator output voltage signal no electricity (See F67 DTC TABLE)
P2503 Battery overcharge (See F67 DTC TABLE)
P2504 Generator terminal B circuit open (See F67 DTC TABLE)
U0073 CAN bus off (See F67 DTC TABLE)
U0121
PCM cannot receive any signals from ABS,
ABS/TCS or DSC HU/CM
(See F67 DTC TABLE)
U0155
PCM cannot receive any signals from
combination meter
(See F67 DTC TABLE)
DTC No. Condition MIL
HOLD
indicator
light
flashes
DC
Monitor
item
Memory
function
Page
DTC P0500 Vehicle speed sensor (VSS) circuit malfunction
DETECTION
CONDITION
• Vehicle speed signal not input after following conditions are met and 4.5 seconds or more have passed
 D, L, or S range.
 Engine coolant temperature 60 °
°°
°C {140 °
°°
°F} or above.
 Turbine speed 1,500 rpm or above.
Diagnostic support note:
• This is a continuous monitor (CCM).
• MIL illuminates if PCM detects the above malfunction condition in two consecutive drive cycles or in one
drive cycle while the DTC for the same malfunction has been stored in the PCM.
• PENDING CODE is available if PCM detects the above malfunction condition during first drive cycle.
• FREEZE FRAME DATA is available.
• HOLD indicator light flashes.
• DTC is stored in the PCM memory.
POSSIBLE
CAUSE
• VSS malfunction
• Open circuit between VSS terminal B and PCM terminal 3C
• Short to ground between VSS terminal B and PCM terminal 3C
• Open circuit between VSS terminal A and fuse block connector (X-01) terminal AJ
• Open circuit between VSS terminal C and body ground
• Damaged connectors between VSS and PCM
• PCM malfunction
