ON-BOARD DIAGNOSTIC (ABS/TCS)
End Of Si e
DTC C1145, C1155, C1165, C1175
A6E697567650W10
Caution
•
••
• When attaching the tester lead to the ABS (ABS/TCS) HU/CM harness connector, the SST (49 G066
001) must be used. (See P29 ABS (ABS/TCS) HU/CM INSPECTION.)
DTC
C1145
C1155
C1165
C1175
RF wheel-speed sensor
LF wheel-speed sensor
RR wheel-speed sensor
LR wheel-speed sensor
DETECTION
CONDITION
• Abnormal input is detected.
POSSIBLE
CAUSE
• Open or short to ground circuit in harness between ABS (ABS/TCS) HU/CM terminal and wheel-speed
sensor(s) terminal below
 ABS (ABS/TCS) HU/CM terminal GRF ABS wheel-speed sensor terminal A
 ABS (ABS/TCS) HU/CM terminal DRF ABS wheel-speed sensor terminal B
 ABS (ABS/TCS) HU/CM terminal ILF ABS wheel-speed sensor terminal A
 ABS (ABS/TCS) HU/CM terminal ELF ABS wheel-speed sensor terminal B
 ABS (ABS/TCS) HU/CM terminal ARR ABS wheel-speed sensor terminal A
 ABS (ABS/TCS) HU/CM terminal BRR ABS wheel-speed sensor terminal B
 ABS (ABS/TCS) HU/CM terminal CLR ABS wheel-speed sensor terminal A
 ABS (ABS/TCS) HU/CM terminal FLR ABS wheel-speed sensor terminal B
• ABS wheel-speed sensor(s) malfunction
